Media Filtration has been followed as most, reliable economical & proven process for removal of suspended solids as pretreatment to different downstream process even in this age of latest development.
CARBON due to its inherent properties of adsorbing color, excess chlorine, organics and odor is still being used as main treatment option or as part of process being selected for the purification of water.
ULTRAFILTRATION is being used more effectively as pretreatment to RO system especially on surface water feed and sea water systems.
DISSOLVED AIR FLOATATION (DAF)
It’s an effective way of removing floating particles along with biological & algael contamination in addition to hydro carbon. The system can be incorporated with in depth filtration from ITT-Leopold.
Highlights
- Fiber Glass reinforced plastic vessels
- Automatic backwash with time controller
- Carefully selected media with excellent uniformity coefficient
- All corrosion resistant internals
- Relaxed filtration rates
- Consistent Product Quality
Optional
- Backwash initiation on pressure difference
- Higher flow available
- PLC controller available
- Carbon steel or stainless steel vessels available
- Duplex service / standby controller
- Activated Carbon, berm, Mangnese Green Sand, Filter AG
| MODEL |
Max.
Filtered
Water flow
M3/hr |
Max.
Working
Pressure
bar |
Min.
Working
Pressure
bar |
Test
Pressure
bar |
Media Volume
liters |
Inlet/
Outlet
Connection
inches |
| Clear-flo 36 |
1.5 |
8.5 |
1.3 |
10.5 |
20 |
1 |
| Clear-flo 60 |
2.5 |
8.5 |
1.3 |
10.5 |
50 |
1 |
| Clear-flo 100 |
4 |
8.5 |
1.3 |
10.5 |
100 |
1.5 |
| Clear-flo 144 |
6 |
8.5 |
1.3 |
10.5 |
200 |
1.5 |
| Clear-flo 216 |
9 |
8.5 |
1.3 |
10.5 |
300 |
1.5 |
| Clear-flo 360 |
15 |
5 |
1.3 |
8 |
650 |
2 |
| Clear-flo 600 |
25 |
5 |
1.3 |
8 |
1250 |
3 |
| Clear-flo 840 |
35 |
5 |
1.3 |
8 |
1700 |
4 |
| Clear-flo 1k |
45 |
5 |
1.3 |
8 |
2000 |
4 |
| Clear-flo 1.3k |
55 |
5 |
1.3 |
8 |
2500 |
4 |
Yet another method effectively to improve the efficiency of your cooling system & protect your system against reduced heat transfer, maintenance, low pressure & spray nozzles.
Highlights
- Feed water design turbidity <10 NTU
- PLC Controlled
- Inside out pressurized
- Strainers
- 80-90% recovery
- SDI less than 3
- Online Turbidity Monitor
- Back wash pump
- Air compressor
Optional
- Media Filtration
- Online Auto CEB
- AIT
- Self-Cleaning Strainer
- Multiple Skids can be used for higher flows
| MODEL |
Output
M3/day |
Output IGPD |
Trans
Membrane
Pressure
bar |
| Clear-flo UF-3 |
300 |
66500 |
0.1 – 0.80 |
| Clear-flo UF-6 |
600 |
135000 |
0.1 – 0.80 |
| Clear-flo UF-9 |
900 |
200000 |
0.1 – 0.80 |
| Clear-flo UF-12 |
1200 |
266500 |
0.1 – 0.80 |
| Clear-flo UF-15 |
1500 |
330000 |
0.1 – 0.80 |
| Clear-flo UF-18 |
1800 |
400000 |
0.1 – 0.80 |
| Clear-flo UF-21 |
2100 |
465000 |
0.1 – 0.80 |
| Clear-flo UF-24K |
2400 |
530000 |
0.1 – 0.80 |
Note: Coagulant &CEB chemical consumption varies with feed quality & with & without MMF
